Запасные части для SMD50, SMD-50HX, SMD-50HXW

Описание товара

SMD50HX/R/RX

1 202 200 070 GEAR ASSY 1

2 203 000 640 WING BOLT 3

3 203 100 100 SPRING WASHER 3

4 200 300 540 COVER 1

5 200 200 921 GEAR CASE 1

6 200 200 911 COVER,INPUT 1

7 200 900 590 SHEET PACKING 1

8 200 201 010 CASING 1

9 200 201 020 CASING COVER 1

10 200 900 460 DIAPHRAGM 1

11 200 200 481 ROD 1

12 200 200 491 CAP-DIAPHRAGM 1

13 200 200 990 SUCTION FLANGE 1

14 200 201 000 BEND 1

15 200 300 410 FITING-PIPE 2

200 300 411 FITING-PIPE (2)

16 200 200 980 CHAMBER 1

17 200 900 150 CHECK VALVE 2

18 200 200 700 PLUG 1

19 200 800 220 O-RING 1

20 200 800 130 O-RING 1

21 203 300 080 GREASE NIPPLE 1

22 203 300 140 NEEDLE BEARING 1

23 200 500 120 COLLAR 2

24 203 100 170 PLAIN WASHER 1

25 203 300 090 KEY 1

26 203 000 040 HEX.BOLT 8

27 203 000 060 HEX.BOLT 4

28 203 000 080 HEX.BOLT 3

29 203 100 140 PLAIN WASHER 3

30 203 000 390 HEX.SOCKET BOLT 1

31 203 100 120 SPRING WASHER 1

32 203 000 130 HEX.BOLT 1

33 200 100 080 FRAME(BLACK) 1

200 100 081 FRAME(WHITE) (1)

200 100 082 FRAME(YELLOW) (1)

200 100 120 FRAME(BLACK) (1)

200 100 121 FRAME(WHITE) (1)

200 100 122 FRAME(YELLOW) (1)

34 200 900 390 ANTI-VIBRATION RUBBEE 2

35 200 900 400 ANTI-VIBRATION RUBBEE 4

36 203 200 030 SPRING NUT 8

37 203 000 320 HEX.BOLT 4

38 203 100 120 SPRING WASHER 4

39 203 100 150 PLAIN WASHER 4

40 201 200 140 STRAINER 1

40A 201 200 150 STRAINER (1)

41 200 900 050 PACKING,COUPLING 2

42 200 200 690 HOSE COUPLING 2

43 200 200 670 HOSE COUPLING HANDLE (2)

200 200 720 HOSE COUPLING HANDLE (2)

44 201 000 040 HOSE BAND
